When an alarm condition has been cleared without
it either being acknowledged or reset the panel will
stop flashing and will change colour to yellow.
Note: Please refer to “Alarm Descriptions and Actions to be Taken” on
page 225 for a detailed list of ventilator alarms.
Note: The battery fail alarm is an audible only alarm, no visual indication is
given.
7.10 Default Waveform Windows
The windows display the waveforms and loops generated during ventilation.
The default waveform layout.
The SLE4000 ventilator default setting is to display: Pressure, Flow and Tidal
volume waveforms for CPAP, CMV, PTV, PSV and SIMV.
The SLE5000 ventilator default setting is to display: Pressure, Flow and Tidal
volume waveforms for CPAP, CMV, PTV, PSV, SIMV and HFO. For HFO+CMV
the ventilator will only display Pressure and Flow waveforms.
The red sweep bar tracks across the windows updating the display.
