Page 18 of 292
Note: PTV will continue to function as stated, but with breath rates of 20 and
above apnoea alarms will be ignored by the ventilator. Breath rates of 20BPM
and above are deemed sufficient to support the patient. Should the breath
rate be set below 20BPM the apnoea alarm is enabled.
2.3.1 PTV with TTV (Targeted Tidal Volume)
This is as for basic PTV where the inspiratory phase shall be truncated when the set volume
has been delivered for mechanical back up breaths only.
The User sets the following:-
• Enables Targeted Tidal Volume (Tidal Vol) and selects volume to be delivered
•Max PIP
•Max Ti
