Page 249 of 292
DIAGRAM INDEX
A Proximal Airway Inlet 1 Humidifier Supply Line
B Exhalation Port (From Patient) 2 Inspiratory Supply Line
C Ø10 x 100 Tube Assembly 3 Expiratory Supply Line
D Single Use Bacteria Filter 4 Proximal Airway Pressure Line
E Autoclavable Bacteria Filter 5 Temperature Monitoring Port
F ET Manifold 6 Inspiratory Supply Line
G Amber Metal Restrictor
H Heater Connection
J Humidifier Chamber - Reference only
K Water Trap
A
B
C
D
E
F
G
H
J
K
1
2
3
4
6
3
5
5
To Next Page
