PIP parameter control: 0 to 65 mbar
Picture capture button: Stores loop to memory
PSV button: Selects PSV mode
PSV Setup: button: Activates pressure support panel
PTV button: Selects PTV mode
Reset button: Resets current alarm
Reset contamination alarm
button:
Resets the alarm
Resistance Trend Button Selects resistance against time display
Return button: Returns to previous panel
Select button: Tabs between time and date values
Set time and date button: Activates time and date panel
Set trigger button: Activate the breath detection threshold
SIMV button: Selects SIMV mode
Standby button: Sets ventilator into 90 second standby mode
Stored loop button: Displays stored loops
Ti parameter: control: 0.1 to 3 seconds
Tid Vol button: Selects tidal volume against time display
Tidal vol parameter: control: 2 to 200 ml
TTV button: Selects TTV on/off panel
Two point O
2
calibration button: Activates calibrates O
2
system
Ventilation Off button: Selects ventilation off mode
Version button: Activates version information panel
V/P Loop button: Selects volume versus pressure loop display
Waveform display sync button: Toggles waveform display synchronization
Waveshaping button: Activates change wave shape panel
Zero button: Zeros seconds
Zoom in button: Zooms in on a trend display
Zoom out button: Zooms out of a trend display
