MR860 Dual Temperature Probe (for 850 F&P

humidifier)

N3860

Test Lung N6647

Basic pole and 5 star base M0770/80

Ventilator Cart with locking front castors, basket and

medi rail. (Shelf height 82cm)

N6627

Ventilator Cart with two locking castors, basket and

medi rail. (Shelf height 99cm)

N6650

Hose Hook N6627/09
