Mains/Battery power indicator (Situated on front panel).
Screen pause.
Waveform display options.
Display options and service data.
Enables the Targated Tidal Volume Panel.
Enables the breath detection threshold in the flow window.
Night mode and Screen Lock.
Return button. Returns the user to previous panel.
Next Button. Advances user to the next panel.
Volume controls.
Symbol Description
