STOBER 8 | Connection
12/2018 | ID 442537.05
105
Single-ended HTL hall sensor
Terminal Pin Designation Function
9|10|11| ... |17|18|19
9 DGND Reference ground, internally bridged
10
11 BE1 HALL A
12 BE2 HALL B
13 BE3 HALL C
14 BE4 Binary input
15 BE5
16 BA1 Binary output
17 BA2
18 +24V
DC
External 24V
DC
supply; recommended fuse
protection: max. 1AT
13
19
Tab. 104: X101 connection description for single-ended HTL hall sensor signals
Connecting wiring
For connecting wiring, observe the terminal specifications in the chapter FK-MCP 1,5 -ST-3,5
[}152].
Cable requirements
Feature All sizes
Max. cable length 30m
Tab. 105: Cable length [m]
8.6.1.4 X102: AE3
Pin Designation Function
1|2
1 AE3+ AE3+ input; differential input voltage
2 AE3− AE3− input
Tab. 106: X102 connection description
Connecting wiring
For connecting wiring, observe the terminal specifications in the chapter FMC 1,5 -ST-3,5
[}151].
Cable requirements
Feature All sizes
Max. cable length 30m
Tab. 107: Cable length [m]
13
For the fuse protection, use a 1A fuse (time delay). For UL-compliant use, be sure that the fuse meets
certification requirements for relevant DC voltage in accordance with UL 248.
