STOBER 8 | Connection
12/2018 | ID 442537.05
67
8.4.1.1 Sizes 0 and 1
2
1
3
4
11
10
12
13
15
16
X4
X1
X2
4
2
3
1
8
7
PE
V
W
U
X20
X30
D
D
R
R
PE
L2
L3
L1
X10
X11
8
6
X3B
X201
5
X3A
7
X200
9
X120
14
X5
6
5
X6
1
3
2
4
5
7
6
8
X12
4
2
3
1
Fig.10: Connection overview of sizes 0 and 1 with ST6 safety module
1 Ground bolt 9 X120: Encoder connection on optional XI6
terminal module (alternatively X120 and
X140: Encoder connections on RI6 terminal
module or IO6 terminal module without
encoder connection)
2 X10: 230/400V
AC
supply 10 X1: Enable and relay 1
3 X11: 24V
DC
supply 11 X4: Encoder
4 X12: ST6 safety technology 12 X2: Motor temperature sensor
5 X3A: PC, IGB 13 X5: Brake 1 (BD1/BD2)
6 X3B: PC, IGB 14 X6: Brake (feedback and supply)
7 X200: EtherCAT on the optional EC6
communication module
(alternatively CANopen on CA6
communication module or
PROFINET on PN6 communication module)
15 X20: Motor
8 X201: EtherCAT on the optional EC6
communication module
(alternatively PROFINET on PN6
communication module)
16 X30: Quick DC-Link, braking resistor
