Suzuki RM250 - Magneto Rotor and Stator; Removal

13-10 ELECTRICAL SYSTEM
MAGNETO ROTOR AND STATOR
REMOVAL
• Remove the seat. (5-4)
• Remove the fuel tank. (5-4)
• Disconnect the magneto lead wire coupler 1 and clamps.
• Remove the magneto cover.
• Remove the magneto rotor nut with the special tool.
 09930-40113: Rotor holder
• Remove the magneto rotor with the special tool.
 09930-30113: Flywheel rotor remover
NOTE:
Fold the gearshift lever head for turning the special tool handle.
