18-18 SERVICING INFORMATION
REAR BRAKE HOSE ROUTING
Stopper
Rear brake caliper
Stopper
Rear brake fluid
reservoir
Guide
Master cylinder
Set the brake hose end between the hose stopper,
then tighten the brake hose union bolt to the specified torque.
Outside
Set the brake hose end between the hose stopper,
then tighten the brake hose union bolt to the specified torque.
