Suzuki RM250 - Rear Suspension Linkage Service

17-16 REAR SUSPENSION
REAR SUSPENSION LINKAGE
CONSTRUCTION
REMOVAL AND DISASSEMBLY
• Place a block under chassis tubes.
• Remove the lower drive chain control roller 1.
• Remove the rear cushion rod bolt and nut.
• Remove the cushion lever bolt and nut.
• Remove the shock absorber lower bolt and nut.
80 N
.
m
(8.0 kgf-m,
58.0 lb-ft)
80 N
.
m
(8.0 kgf-m,
58.0 lb-ft)
80 N
.
m
(8.0 kgf-m,
58.0 lb-ft)
