REAR SUSPENSION 17-3
INSPECTION
• Inspect the rear shock absorber for oil leakage.
• Inspect the damper rod for bends and smooth movement.
• Inspect the bump rubber for deterioration and damage.
• Inspect the spacers and dust seals for damage.
• Inspect the bearing for excessive play and smooth movement.
SPRING REPLACEMENT
• Loosen the lock-nut 1 using the special tool and turn it to the
end of the thread.
• Turn the adjuster 2 as well as the lock-nut 1.
 09910-60611: Universal clamp wrench
• Depress the spring seat 3 and remove the stopper ring 4.
• Remove the spring seat 3 and the spring 5 from the rear
shock absorber.
NOTE:
Install the spring as painted side A or small diameter side is bot-
tom.
• Fit the lock-nut, adjuster, spring, spring seat and stopper ring.
