Suzuki RM250 - Bearing Replacement; Installation

REAR SUSPENSION 17-15
BEARING REPLACEMENT
• Remove the bearing using the special tool.
 09921-20240: Bearing remover set
• Apply grease to new bearings.
 99000-25010: SUZUKI SUPER GREASE “A”
(or equivalent grease)
• Press the bearing with the special tool.
 09924-84521: Bearing installer set
INSTALLATION
Reassemble and remount the swingarm in the reverse order of
removal and disassembly. Pay attention to the following points:
• Apply grease to the spacers, dust seals and bearings.
 99000-25010: SUZUKI SUPER GREASE “A”
(or equivalent grease)
• Tighten the swingarm pivot shaft nut to the specified torque.
 Swingarm pivot nut: 70 N·m (7.0 kgf-m, 50.5 lb-ft)
• Tighten the rear cushion lever nut to the specified torque.
 Rear cushion lever nut: 80 N·m (8.0 kgf-m, 58.0 lb-ft)
• Install the brake pedal. (5-9)
• Adjust the drive chain slack. (2-16)
