Suzuki RM250 - Exhaust Valve Governer and Actuator; Disassembly

CYLINDER, PISTON AND EXHAUST VALVE 6-19
EXHAUST VALVE GOVERNER AND
ACTUATOR
DISASSEMBLY
• Drain the transmission oil. (2-10)
• Drain the engine coolant. (2-12)
• Remove the exhaust pipe. (5-5)
• Remove the exhaust side valve cover. (6-5)
• Remove the right crankcase cover. (8-3)
• Disconnect the exhaust valve governer rod bolt.
• Remove the exhaust governer assembly 1.
• Remove the exhaust valve rod assembly 2.
• Remove the pin 3 by pushing down the retainer 4.
