Suzuki RM250 - Disc Plate Replacement; Installation

FRONT AND REAR WHEELS 14-5
DISC PLATE REPLACEMENT
• Remove the disc plate.
• Apply THREAD LOCK SUPER to the bolts.
99000-32110: THREAD LOCK SUPER “1322”
(or equivalent thread lock)
• Install a new disc plate and tighten the bolts to the specified
torque.
 Disc plate bolt: 10 N·m (1.0 kgf-m, 7.0 lb-ft)
INSTALLATION
• Hold the axle shaft with the special tool and tighten the axle
nut temporarily.
 09940-34581: Attachment (F)
• Remove the block from under the chassis tube and move the
front forks up and down several times.
• Tighten the axle nut to the specified torque.
 Axle nut: 35 N·m (3.5 kgf-m, 25.5 lb-ft)
• Tighten the left and right axle holder bolts to the specified
torque.
 Axle holder bolt: 18 N·m (1.8 kgf-m, 13.0 lb-ft)
