FRONT AND REAR WHEELS 14-7
REMOVAL
• Place the motorcycle on a block to lift rear wheel off the
ground.
• Remove axle nut 1 and washer 2.
• Loosen the chain adjuster lock-nuts 3 and chain adjuster
bolts 4.
• Remove the rear axle shaft 5 and chain adjuster washers 6.
• Remove the rear wheel.
INSPECTION
SPACER AND DUST SEAL (14-3)
AXLE SHAFT (14-3)
 Axleshaft runout
Service Limit: 0.25 mm (0.010 in)
WHEEL RIM (2-21)
 Service Limit: 2.0 mm (0.08 in) ... axial and radial
WHEEL BEARING (14-4)
REAR SPROCKET (2-17)
