Suzuki RM250 - Rear Sprocket Replacement; Installation

FRONT AND REAR WHEELS 14-9
REAR SPROCKET REPLACEMENT
• Remove the rear sprocket.
NOTE:
Install the rear sprocket so the letters on the sprocket surface
face outside.
• Tighten the bolts/nuts to the specified torque.
 Rear sprocket bolt/nut: 30 N·m (3.0 kgf-m, 21.5 lb-ft)
INSTALLATION
• Install the chain adjuster washers as shown.
• Adjust the drive chain slack. (2-16)
• Tighten the axle nut to the specified torque.
 Rear axle nut: 100 N·m (10.0 kgf-m, 72.5 lb-ft)
FWD
Left
Right
Chain adjuster washer
