18-14 SERVICING INFORMATION
CABLE ROUTING
Throttle cable
Throttle cable
Clutch cable
Clutch cable
Clamp
Pass the clutch cable
between the engine
mounting brackets.
Throttle cable
Clutch cable
Pass the clutch cable under
the radiator breather hose.
