FRONT AND REAR BRAKES 15-3
• Apply SUZUKI SILICONE GREASE to the O-ring.
99000-25100: SUZUKI SILICONE GREASE
• Fit new brake pads into the caliper and tighten the pad mount-
ing pin to the specified torque.
Brake pad mounting pin: 18 N·m (1.8 kgf-m, 13.0 lb-ft)
NOTE:
* Pump the brake pedal several times to seat the brake pads
after reassembling.
* Inspect not to pinch the O-ring of brake pad pin.
