Suzuki RM250 - Page 244

REAR SUSPENSION 17-19
• Tighten the cushion lever, cushion rod and swingarm nuts to the specified torque.
 Tightening torque:
A: 55 N·m (5.5 kgf-m, 40.0 lb-ft)
B: 55 N·m (5.5 kgf-m, 40.0 lb-ft)
C: 80 N·m (8.0 kgf-m, 58.0 lb-ft)
D: 80 N·m (8.0 kgf-m, 58.0 lb-ft)
E: 80 N·m (8.0 kgf-m, 58.0 lb-ft)
F: 70 N·m (7.0 kgf-m, 50.5 lb-ft)
5 mm
4 mm
4 mm
4 mm
Left Right
