5-6 ENGINE REMOVAL AND INSTALLATION
• Remove the cotter pins and brake pedal 0.
• Remove the magneto cover. (13-10)
• Disconnect the clutch cable.
NOTE:
Loosen the clutch cable adjuster when disconnecting.
(2-13)
• Extract the clutch cable A.
• Remove the sprocket cover B.
• Remove the engine mounting bolts and brackets.
• Remove the swingarm pivot shaft nut and washer.
