150

SVAN 977A User Manual - Appendixes

The instrument outputs in this case a file containing all control settings given in Tab. A1

in the format:

#1,Xccc,Xccc,(...),Xccc;

Note: All bytes of that transmission are ASCII characters.

A.2. FUNCTION #2 – READ OUT OF THE MAIN MEASUREMENT RESULTS

#2 function enables one to read out the current measurement results from the selected profile.

#2 function has the formats defined as follows:

#2 [,<aver>] [,<profile>] [[[ ,X? ] ,X? ] ,(...) ];

#2 [,<aver>] ,<rot>;

where:

<aver> – type of results:

i – instantaneous results, i.e. results from the current cycle (default),

a – averaged results, i.e. results from the previous cycle.

<profile> – profile number:

0 – means “all profiles”, i.e. results from the all profiles will be sent (default value),

1, 2 or 3 – one of the profile, i.e. only results from the given profile will be sent;

<rot> – rotation results:

rpm – all rotations results will be sent (unit of the results wil be [rpm]),

rps – all rotations results will be sent (unit of the results wil be [rps]);

X – code of the specified result (see below); if no code are specified all results will be sent;

In case of <profile> = 1, 2 or 3 the instrument sends results in the format defined as follows:

#2 [,<aver>],<profile>,Xc,(...);

where c is the value of the result X or question mark (?) if result X is not available;

In case of <profile> = 0 the instrument sends results in the format defined as follows:

#2 [,<aver>],1,Xc,(...),2,Xc,(...),3,Xc,(...),;

where c is the value of the result X or question mark (?) if result X is not available;

If no results are available, the instrument will send:

#2,?;
