C.1.1 Specification of SVAN 977A as SLM in the standard configuration
SVAN 977A working as the SLM with all listed below accessories meets requirements of the IEC 61672:2013
for the Class 1 instruments.
The configuration of the complete SLM and its normal mode of operation
SVAN 977A sound & vibration analyser
SV 12L microphone preamplifier
A.C.O. 7052E measuring prepolarized free-field microphone (1/2", nominal
sensitivity 35 mV/Pa, polarization 0 V)
SV 36 Class 1 sound calibrator: 94/114 dB@1000 Hz, B&K 4231 (or
equivalent)
Accessories included in SVAN 977A instrument set
SC 16 USB cable
SA 22 windscreen
Accessories available:
SV 55 RS 232 interface for SVAN 977A
SA 277 outdoor protection unit
SC 26 extension cable for SV 12L (TNC plug to TNC socket)
SA 15 power supply unit
Measured quantities
The measured quantities in the sound meter mode are: PEAK, SPL, MAX, MIN, LEQ, Leq, SEL, Ltm3,
LTeq, Lden, LEPd, Lnn.
Definitions for parameters are given in Appendix D.
Additional functions
Overload indication see Chapter 3 or Appendix A
Under-range indication see Chapter 3 or Appendix A
Battery state indication see Chapter 3
Conformance testing
This chapter contains the information needed to conduct conformance testing according to the specified
standards.
Mounting for acoustical tests The microphone must be mounted on the preamplifier.
Electrical substitute for the microphone To obtain a BNC Class electrical input, the microphone
must be replaced by an electrical microphone impedance
ST 02 with the serial capacitance 18 pF ± 10%.
