Svantek SVAN 977A - Structure of the File Containing Results from Loggers File

194
SVAN 977A User Manual - Appendixes
Word
number
Name
Comment
13+i
cor_rt_20[i]
i=N1_rt60_freq÷N2_rt60_freq;
i=N_tercje÷N_tercje+N_max_total-1
14+i
cor_rt_30[i]
i=N1_rt60_freq÷N2_rt60_freq;
i=N_tercje÷N_tercje+N_max_total-1
15+i
cor_rt_user[i]
i=N1_rt60_freq÷N2_rt60_freq;
i=N_tercje÷N_tercje+N_max_total-1
…
…
…
Table B.1.34 SETUP file
Word
number
Name
Comment
0
0x0020
[20, 00=block’s length in the second word]
1
BlockLength
length of the block
2..BlockLen
gth-1
SetupTextData
saved setup values
Table B.1.35 SETUP file end marker
Word
number
Name
Comment
0
0xFFFF
end marker
B.2. STRUCTURE OF THE FILE CONTAINING RESULTS FROM LOGGER’S FILE
SvanPC file header (cf. Table B.1.1);
File header (cf. Table B.1.2);
Unit and internal software specification (cf. Table B.1.3);
Calibration settings (cf. Table B.1.4);
USER’S text (cf. Table B.1.5);
Parameters and global settings (cf. Table B.1.6);
MEASUREMENT TRIGGER settings (cf. Table B.1.7);
LOGGER TRIGGER settings (cf. Table B.1.8);
Time-domain signal recording parameters (cf. Table B.1.9);
Wave-file recording parameters (cf. Table B.1.10);
Extended I/O parameters (cf. Table B.1.11);
Special settings for profiles (cf. Table B.1.12, Table B.1.13);
RTF parameters (cf. Table B.1.14);
Marker parameters (cf. Table B.1.15);
Header of the statistical analysis (cf. Table B.1.16);
Header of the 1/x OCTAVE analysis (cf. Table B.1.17);
Header of the statistical analysis performed in 1/x OCTAVE mode (cf. Table B.1.18);
Header of the FFT analysis (cf. Table B.1.19);
RT60 parameters (cf. Table B.1.20);
Header of the logger file (cf. Table B.1.21);
Contents of the logger file (cf. Table B.1.22);
