SVAN 977A User Manual - Appendixes
A.6. CONTROL SETTING CODES
The control setting codes used in the SVAN 977A instrument are given in the table below.
Table A.1. Control setting codes
Group name
Group
code
Code description
Unit type
U
U977 (read only)
Serial number
N
Nxxxx (read only)
Software version
W
Wx.xx.x x.xx.x - revision number (read only)
Calibration factor
Q
Qn.nn n.nn - calibration factor in dB
Meter mode
Z
Z0 - Vibration Meter
Z1 - Sound Meter
Direct Input
V
V0 - Off
V1 - On
Measurement function
M
M1 - Level Meter
M2 - 1/1 Octave
M3 - 1/3 Octave
M6 - FFT
Range
R
R1 - Low
R2 - High
Filter type in profile n
in SLM mode
F
F1:n Z filter for profile n
F2:n A filter for profile n
F3:n C filter for profile n
F5:n B filter for profile n
Detector type in profile n in SLM mode
C
C0:n - Impulse detector in profile n
C1:n - Fast detector in profile n
C2:n - Slow detector in profile n
Logger type in profile n
in SLM mode
B
Bx:n - x - sum of the following flags
flags:
1 - logger with Peak values in profile n
2 - logger with Max values in profile n
4 - logger with Min values in profile n
8 - logger with RMS values in profile n
