SVAN 977A User Manual - Appendixes
C.3. SPECIFICATION OF SVAN 977A AS 1/1 OCTAVE AND 1/3 OCTAVE ANALYSER
SVAN 977A can operate as 1/1-octave or 1/3-octave analyser conforming to the international IEC 61260-
1:2014 standard for the pass band filters.
Note: Simultaneously to the frequency analysis SVAN 977A operates as Sound Level Meter! See
Chapters C.1 for specification.
Signal input
● SV12L preamplifier throughout ST02 adapter
● Maximum input voltage: SVAN 977A meets the requirements IEC 348 for the 2
nd
class device. The input
voltage shall not exceed the limits between -15 V and +15 V.
● Impedance: 10 G / 2 pF.
Linear Operating Ranges
Two measuring ranges are available: “LOW” and "HIGH"
Table C.3.1 Linear operating range
Range
Linear operating range (with 10 dB margin from noise)
(RMS for the sinusoidal signal at reference conditions @ 1 kHz,
0.0 dB calibration factor)
LOW
from 9 μV
RMS
“A”-weighting
to 0.99 V
RMS
“A”-weighting
LOW
from 9 μV
RMS
“B”-weighting
to 0.99 V
RMS
“B”-weighting
LOW
from 9 μV
RMS
“C”-weighting
to 0.99 V
RMS
“C”-weighting
LOW
from 22 μV
RMS
“Z”-weighting
to 0.99 V
RMS
“Z”-weighting
HIGH
from 22 μV
RMS
“A”-weighting
to 4.96 V
RMS
“A”-weighting
HIGH
from 22 μV
RMS
“B”-weighting
to 4.96 V
RMS
“B”-weighting
HIGH
from 22 μV
RMS
“C”-weighting
to 4.96 V
RMS
“C”-weighting
HIGH
from 56 μV
RMS
“Z”-weighting
to 4.96 V
RMS
“Z”-weighting
Table C.3.2 Peak for the sinusoidal signal 1 kHz, at reference conditions
Peak for the sinusoidal signal 1 kHz, at reference conditions
@ 1 kHz (0.0 dB calibration factor)
Range
Max Peak value
LOW
1.4 V “A”–weighting
LOW
1.4 V “B”–weighting
LOW
1.4 V “C”-weighting
LOW
1.4 V “Z”-weighting
HIGH
7 V “A”-weighting
HIGH
7 V “B”–weighting
HIGH
7 V “C”-weighting
HIGH
7 V “Z”-weighting
