SVAN 977A User Manual - Appendixes
Group name
Group
code
Code description
Filter type in profile n
in VLM mode
I
I0:n HP filter for profile n
I1:n HP1 filter for profile n
I2:n HP3 filter for profile n
I3:n HP10 filter for profile n
I4:n Vel11 filter for profile n
I5:n Vel3 filter for profile n
I6:n Vel10 filter for profile n
I7:n VelMF filter for profile n
I8:n Dil1 filter for profile n
I9:n Dil3 filter for profile n
I10:n Dil10 filter for profile n
I21:n Wh filter for profile n
Detector type in profile n in VLM mode
E
E0:n - 100ms detector in profile n
E1:n - 125ms detector in profile n
E2:n - 200ms detector in profile n
E3:n - 500ms detector in profile n
E4:n - 1.0s detector in profile n
E5:n - 2.0s detector in profile n
E6:n - 5.0s detector in profile n
E7:n - 10.0s detector in profile n
Logger type in profile n
in VLM mode
G
Gx:n - x - sum of the following flags:
1 - logger with Peak values in profile n
2 - logger with P–P values in profile n
4 - logger with Max values in profile n
8 - logger with RMS values in profile n
Delay in the start of measurement
Y
Ynn nn delay given in seconds (0  60)
Start Synchronization
u
u0 Off
u1 Sync. to full minute
u15 Sync. to the full 15 minutes
u30 Sync. to the full 30 minutes
u60 Sync. to a full hour
Integration period
D
D0 - infinity (measurement finished by pressing
the <STOP> push-button or remotely by
sending S0 control code)
Dnns nn number in seconds
Dnnm nn number in minutes
Dnnh nn number in hours
Repetition of the measurement cycles
(RepCycle)
K
K0 - infinity (measurement finished by pressing
the <STOP> push-button or remotely - by
sending S0 control code)
.....................
Knnnn - nnnn number of repetitions (1  1000)
