222
SVAN 977A User Manual - Appendixes
Table C.2.1 Linear operating ranges with the Wh filter
Range (RMS)
Linear operating ranges (RMS)
With the SV80 (10 mV/ms
-2
) accelerometer sensitivity @ 79.58 Hz
Measured at the reference environmental conditions
LOW
from 3.16 mms
-2
(70 dB)
to 100 ms
-2
(140 dB)
HIGH
from 31.6 mms
-2
(100 dB)
to 352 ms
-2
(151 dB)
• Linear measurement with the HP, HP1, HP3 and HP10 filters:
from 0.01 ms
-2
to 352 ms
-2
(the sinusoidal signal RMS)
from 0.1 ms
-2
to 500 ms
-2
(PEAK)
Table C.2.2 Linear operating ranges with the HP, HP1, HP3 and HP10 filters
Range (RMS)
Linear operating ranges (RMS)
With the SV80 (10 mV/ms
-2
) accelerometer sensitivity @ 79.58 Hz
Measured at the reference environmental conditions
LOW
from 0.01 ms
-2
(80.0 dB)
to 100 ms
-2
(140.0 dB)
HIGH
from 0.1 ms
-2
(100.0 dB)
to 352 ms
-2
(151.0 dB)
• Linear measurement with the Vel1 filter:
from 0.002 ms
-1
to 56 ms
-1
(the sinusoidal signal RMS)
from 0.02 ms
-1
to 79 ms
-1
(PEAK)
Table C.2.3 Linear operating ranges with the Vel1 filter
Range (RMS)
Linear operating ranges (RMS)
With the SV80 (10 mV/ms
-2
) accelerometer sensitivity @ 79.58 Hz
Measured at the reference environmental conditions
LOW
from 2 mms
-1
to 15.9 ms
-1
HIGH
from 20 mms
-1
to 56 ms
-1
• Linear measurement with the Vel3 filter:
from 0.001 ms
-1
to 26.5 ms
-1
(the sinusoidal signal RMS)
from 0.01 ms
-1
to 37.4 ms
-1
(PEAK)
Table C.2.4 Linear operating ranges with the Vel3 filter
Range (RMS)
Linear operating ranges (RMS)
With the SV80 (10 mV/ms
-2
) accelerometer sensitivity @ 79.58 Hz
Measured at the reference environmental conditions
LOW
from 1 mms
-1
to 5.3 ms
-1
HIGH
from 10 mms
-1
to 26.5 ms
-1
• Linear measurement with the Vel10 and MFVel filters:
from 0.001 ms
-1
to 5.6 ms
-1
(the sinusoidal signal RMS)
from 0.01 ms
-1
to 7.9 ms
-1
(PEAK)
