Svantek SVAN 977A - Page 261

261
SVAN 977A User Manual - Appendixes
f [Hz]
ACO 7052E
Actuator to Free Field
correction for 90 deg
incidence angle
ACO 7052E
Typical electrostatic
actuator response
ACO 7052E
Free Field response
for 90 deg incidence
angle
1830.21
0.00
-0.29
-0.29
1883.65
-0.03
-0.30
-0.32
1938.65
-0.06
-0.31
-0.37
1995.26
-0.08
-0.33
-0.41
2053.53
-0.09
-0.34
-0.43
2113.49
-0.07
-0.35
-0.43
2175.20
-0.04
-0.37
-0.41
2238.72
0.00
-0.39
-0.39
2304.09
0.04
-0.41
-0.37
2371.37
0.05
-0.42
-0.37
2440.62
0.07
-0.44
-0.38
2511.89
0.07
-0.47
-0.40
2585.23
0.06
-0.50
-0.44
2660.73
0.04
-0.53
-0.49
2738.42
0.04
-0.57
-0.53
2818.38
0.01
-0.59
-0.58
2900.68
-0.01
-0.61
-0.62
2985.38
-0.02
-0.64
-0.65
3072.56
-0.01
-0.67
-0.68
3162.28
-0.01
-0.69
-0.70
3254.62
0.00
-0.73
-0.73
3349.65
0.01
-0.78
-0.76
3447.47
0.01
-0.82
-0.81
3548.13
-0.03
-0.86
-0.89
3651.74
-0.07
-0.91
-0.98
3758.37
-0.10
-0.96
-1.06
3868.12
-0.09
-1.01
-1.10
3981.07
-0.07
-1.06
-1.13
4097.32
0.00
-1.12
-1.11
4216.97
0.07
-1.18
-1.11
4340.10
0.11
-1.24
-1.12
4466.84
0.10
-1.29
-1.18
4597.27
0.08
-1.34
-1.26
4731.51
0.03
-1.40
-1.37
4869.68
0.02
-1.47
-1.45
5011.87
0.00
-1.53
-1.53
5158.22
0.02
-1.62
-1.60
5308.84
0.02
-1.70
-1.68
5463.87
0.01
-1.78
-1.77
5623.41
-0.02
-1.87
-1.89
5787.62
-0.04
-1.96
-2.01
5956.62
-0.07
-2.04
-2.11
6130.56
-0.06
-2.14
-2.20
6309.57
-0.02
-2.24
-2.26
6493.82
0.02
-2.34
-2.32
6683.44
0.08
-2.44
-2.36
6878.60
0.12
-2.55
-2.43
