SVAN 977A User Manual - Appendixes
Free Field Frequency response of SVAN 977A with SA 277 (0 deg incidence angle)
Table C.7.11 SVAN 977A with SA 277 frequency response (0 deg incidence angle)
f [Hz]
Typical non-compensated
frequency response of
SVAN 977A with SA 277 for
0 deg incidence angle
Compensation
filter
“Airport”
Typical compensated
frequency response of
SVAN 977A with SA 277 for
0 deg incidence angle (Airport)
251.19
-0.10
-0.02
-0.12
258.52
-0.06
-0.02
-0.08
266.07
-0.03
-0.02
-0.05
273.84
-0.02
-0.02
-0.04
281.84
-0.03
-0.02
-0.05
290.07
-0.05
-0.02
-0.07
298.54
-0.07
-0.02
-0.09
307.26
-0.08
-0.03
-0.11
316.23
-0.09
-0.03
-0.12
325.46
-0.09
-0.03
-0.12
334.97
-0.08
-0.03
-0.11
344.75
-0.07
-0.03
-0.10
354.81
-0.05
-0.03
-0.08
365.17
-0.03
-0.04
-0.07
375.84
-0.01
-0.04
-0.05
386.81
0.03
-0.04
-0.01
398.11
0.06
-0.04
0.02
409.73
0.07
-0.05
0.02
421.70
0.04
-0.05
-0.01
434.01
-0.02
-0.05
-0.07
446.68
-0.05
-0.06
-0.11
