RemovingtheEngine
1.Parkmachineonalevelsurface,lowercuttingdeck(orimplement),shutoff
theengine,andremovekeyfromthekeyswitch.Chockwheelstokeep
themachinefrommoving.
2.Openhood;refertotheTractionUnitOperator’sManual.
3.Disconnectnegative(-)andthenpositive(+)batterycablesatthebattery.
4.Removebatteryfrommachine;refertoServicingtheBattery(page6–80).
g230309
Figure16
1.Battery3.Batterybase5.Lockwasher
2.Bolt(3each)4.Flangenut(3each)6.Groundcable
5.Removeboltsandangenutsthatsecurebatterybasetobrackets.Remove
batterybasefrommachine(Figure16).
CAUTION
Donotopenradiatorcapordraincoolantiftheradiatororengineis
hot.Pressurized,hotcoolantcanescapeandcauseburns.
Ethylene-glycolantifreezeispoisonous.Disposeofcoolantproperly,
orstoreitinaproperlylabeledcontainerawayfromchildrenand
pets.
6.Draincoolantfromradiator;refertotheTractionUnitOperator’sManual.
GasolineEngine:ServiceandRepairs
Page3–16
Groundsmaster
®
3280-D/3320
05138SLRevB
