0-** Operation and Display
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
0-0* Basic Settings
0-01 Language [22] English US 1 set-up TRUE - Uint8
0-02 Motor Speed Unit [1] Hz 2 set-ups FALSE - Uint8
0-03 Regional Unit Settings
[0] North Amer-
ica 2 set-ups FALSE - Uint8
0-04 Operating State at Power-up [0] Resume All set-ups TRUE - Uint8
0-05 Local Mode Unit
[0] As Motor
Speed Unit 2 set-ups FALSE - Uint8
0-1* Set-up Operations
0-10 Active Set-up [1] Set-up 1 1 set-up TRUE - Uint8
0-11 Programming Set-up
[9] Active Set-
up
All set-ups TRUE - Uint8
0-12 This Set-up Linked to [0] Not linked All set-ups FALSE - Uint8
0-13 Readout: Linked Set-ups 0 N/A All set-ups FALSE 0 Uint16
0-14
Readout: Prog. Set-ups /
Channel 0 N/A All set-ups TRUE 0 Int32
0-2* LCP Display
0-20 Display Line 1.1 Small
[1662] Analog
Input 53 All set-ups TRUE - Uint16
0-21 Display Line 1.2 Small 1614 All set-ups TRUE - Uint16
0-22 Display Line 1.3 Small
[1611] Power
[hp] All set-ups TRUE - Uint16
0-23 Display Line 2 Large 1613 All set-ups TRUE - Uint16
0-24 Display Line 3 Large 1502 All set-ups TRUE - Uint16
0-25 My Personal Menu
ExpressionLi-
mit
1 set-up TRUE 0 Uint16
0-3* LCP Custom Readout
0-30 Custom Readout Unit [1] % All set-ups TRUE - Uint8
0-31 Custom Readout Min Value
ExpressionLi-
mit All set-ups TRUE -2 Int32
0-32 Custom Readout Max Value
100.00 Custom-
ReadoutUnit
All set-ups TRUE -2 Int32
0-37 Display Text 1
ExpressionLi-
mit 1 set-up TRUE 0 VisStr[25]
0-38 Display Text 2
ExpressionLi-
mit
1 set-up TRUE 0 VisStr[25]
0-39 Display Text 3
ExpressionLi-
mit 1 set-up TRUE 0 VisStr[25]
0-4* LCP Keypad
0-40 Hand Start Button [0] Disabled All set-ups TRUE - Uint8
0-41 [Off] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-42 [Auto on] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-43 [Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-44 [Off/Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-45 [Drive Bypass] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-5* Copy/Save
0-50 LCP Copy [0] No copy All set-ups FALSE - Uint8
How to program the Frequency Converter
BAS-SVX19C-EN 6-63
