4-** Limits / Warnings
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
4-1* Motor Limits
4-10 Motor Speed Direction
[2] Both direc-
tions All set-ups FALSE - Uint8
4-11
Motor Speed Low Limit
[RPM]
ExpressionLi-
mit
All set-ups TRUE 67 Uint16
4-12 Motor Speed Low Limit [Hz]
22 Hz IntelliPak
35 Hz Voyager
III All set-ups TRUE -1 Uint16
4-13
Motor Speed High Limit
[RPM]
ExpressionLi-
mit
All set-ups TRUE 67 Uint16
4-14 Motor Speed High Limit [Hz]
ExpressionLi-
mit All set-ups TRUE -1 Uint16
4-16 Torque Limit Motor Mode 110.0 % All set-ups TRUE -1 Uint16
4-17
Torque Limit Generator
Mode 100.0 % All set-ups TRUE -1 Uint16
4-18 Current Limit 100.0 % All set-ups TRUE -1 Uint32
4-19 Max Output Frequency
ExpressionLi-
mit All set-ups FALSE -1 Uint16
4-5* Adj. Warnings
4-50 Warning Current Low 0.00 A All set-ups TRUE -2 Uint32
4-51 Warning Current High
ImaxVLT
(P1637)
All set-ups TRUE -2 Uint32
4-52 Warning Speed Low 0 RPM All set-ups TRUE 67 Uint16
4-53 Warning Speed High
outputSpeed-
HighLimit
(P413)
All set-ups TRUE 67 Uint16
4-54 Warning Reference Low
-999999.999 N/
A All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low
-999999.999
ProcessCtrlUnit All set-ups TRUE -3 Int32
4-57 Warning Feedback High
999999.999
ProcessCtrlUnit
All set-ups TRUE -3 Int32
4-58
Missing Motor Phase Func-
tion [2] Trip 1000 ms All set-ups TRUE - Uint8
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
ExpressionLi-
mit All set-ups TRUE 67 Uint16
4-61 Bypass Speed From [Hz]
ExpressionLi-
mit
All set-ups TRUE -1 Uint16
4-62 Bypass Speed To [RPM]
ExpressionLi-
mit All set-ups TRUE 67 Uint16
4-63 Bypass Speed To [Hz]
ExpressionLi-
mit
All set-ups TRUE -1 Uint16
4-64 Semi-Auto Bypass Set-up [0] Off All set-ups FALSE - Uint8
How to program the Frequency Converter
BAS-SVX19C-EN 6-71
