6-14 Terminal 53 Low Ref./Feedb. Value
Range: Function:
0.000* [-999999.999 - 999999.999 ] Enter the analog input scaling value that corresponds to the low voltage/
low current set in par. 6-10
Terminal 53 Low Voltage and par. 6-12 Ter-
minal 53 Low Current.
6-15 Terminal 53 High Ref./Feedb. Value
Range: Function:
Applica-
tion de-
pend-
ent*
[-999999.999 - 999999.999 ] Enter the analog input scaling value that corresponds to the high voltage/
high current value set in par. 6-11
Terminal 53 High Voltage and
par. 6-13
Terminal 53 High Current.
6-16 Terminal 53 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter time
constant for suppressing electrical noise in terminal 53. A high time con-
stant value improves dampening but also increases the time delay
through the filter.
This parameter cannot be adjusted while the motor is running.
6-17 Terminal 53 Live Zero
Option: Function:
This parameter makes it possible to disable the Live Zero monitoring.
E.g. to be used if the analog outputs are used as part of a de-central I/O
system (e.g. when not as part of any frequency converter related control
functions, but feeding a Building Management system with data).
[0] Disabled
[1] * Enabled
6-20 Terminal 54 Low Voltage
Range: Function:
0.07 V* [Application dependant] Enter the low voltage value. This analog input scaling value should cor-
respond to the low reference/feedback value, set in par. 6-24
Terminal 54
Low Ref./Feedb. Value.
6-21 Terminal 54 High Voltage
Range: Function:
10.00 V* [Application dependant] Enter the high voltage value. This analog input scaling value should cor-
respond to the high reference/feedback value set in par. 6-25
Terminal
54 High Ref./Feedb. Value.
6-22 Terminal 54 Low Current
Range: Function:
4.00
mA*
[Application dependant] Enter the low current value. This reference signal should correspond to
the low reference/feedback value, set in par. 6-24
Terminal 54 Low Ref./
Feedb. Value. The value must be set at >2 mA in order to activate the Live
Zero Time-out Function in par. 6-01
Live Zero Timeout Function.
How to program the Frequency Converter
6-38 BAS-SVX19C-EN
