3-** Reference / Ramps
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
3-0* Reference Limits
3-02 Minimum Reference
ExpressionLi-
mit All set-ups TRUE -3 Int32
3-03 Maximum Reference
ExpressionLi-
mit
All set-ups TRUE -3 Int32
3-04 Reference Function null All set-ups TRUE - Uint8
3-1* References
3-10 Preset Reference 0.00 % All set-ups TRUE -2 Int16
3-11 Jog Speed [Hz]
ExpressionLi-
mit
All set-ups TRUE -1 Uint16
3-13 Reference Site
[0] Linked to
Hand / Auto All set-ups TRUE - Uint8
3-14 Preset Relative Reference 0.00 % All set-ups TRUE -2 Int32
3-15 Reference 1 Source
[1] Analog in-
put 53 All set-ups TRUE - Uint8
3-16 Reference 2 Source
[20] Digital
pot.meter
All set-ups TRUE - Uint8
3-17 Reference 3 Source [0] No function All set-ups TRUE - Uint8
3-19 Jog Speed [RPM]
ExpressionLi-
mit
All set-ups TRUE 67 Uint16
3-4* Ramp 1
3-40 Ramp 1 Type [0] Linear All set-ups TRUE - Uint8
3-41 Ramp 1 Ramp-up Time 30 Sec. All set-ups TRUE -2 Uint32
3-42 Ramp 1 Ramp-down Time 30 Sec. All set-ups TRUE -2 Uint32
3-45
Ramp 1 S-ramp Ratio at Ac-
cel. Start 50 % All set-ups TRUE 0 Uint8
3-46
Ramp 1 S-ramp Ratio at Ac-
cel. End
50 % All set-ups TRUE 0 Uint8
3-47
Ramp 1 S-ramp Ratio at De-
cel. Start 50 % All set-ups TRUE 0 Uint8
3-48
Ramp 1 S-ramp Ratio at De-
cel. End
50 % All set-ups TRUE 0 Uint8
3-5* Ramp 2
3-50 Ramp 2 Type [0] Linear All set-ups TRUE - Uint8
3-51 Ramp 2 Ramp up Time
ExpressionLi-
mit All set-ups TRUE -2 Uint32
3-52 Ramp 2 Ramp down Time
ExpressionLi-
mit
All set-ups TRUE -2 Uint32
3-55
Ramp 2 S-ramp Ratio at Ac-
cel. Start 50 % All set-ups TRUE 0 Uint8
3-56
Ramp 2 S-ramp Ratio at Ac-
cel. End
50 % All set-ups TRUE 0 Uint8
3-57
Ramp 2 S-ramp Ratio at De-
cel. Start 50 % All set-ups TRUE 0 Uint8
3-58
Ramp 2 S-ramp Ratio at De-
cel. End
50 % All set-ups TRUE 0 Uint8
How to program the Frequency Converter
