6-23 Terminal 54 High Current
Range: Function:
20.00
mA*
[Application dependant] Enter the high current value corresponding to the high reference/feed-
back value set in par. 6-25
Terminal 54 High Ref./Feedb. Value.
6-24 Terminal 54 Low Ref./Feedb. Value
Range: Function:
0.000* [-999999.999 - 999999.999 ] Enter the analog input scaling value that corresponds to the low voltage/
low current value set in par. 6-20
Terminal 54 Low Voltage and
par. 6-22
Terminal 54 Low Current.
6-25 Terminal 54 High Ref./Feedb. Value
Range: Function:
100.000
*
[-999999.999 - 999999.999 ] Enter the analog input scaling value that corresponds to the high voltage/
high current value set in par. 6-21
Terminal 54 High Voltage and
par. 6-23
Terminal 54 High Current.
6-26 Terminal 54 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter time
constant for suppressing electrical noise in terminal 54. A high time con-
stant value improves dampening but also increases the time delay
through the filter.
This parameter cannot be adjusted while the motor is running.
