3-11 Jog Speed [Hz]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] The jog speed is a fixed output speed at which the frequency converter
is running when the jog function is activated.
See also par. 3-80
Jog Ramp Time.
Applica-
tion de-
pend-
ent*
[Application dependant]
5-12 Terminal 27 Digital Input
Same options and functions as par. 5-1*, except for
Pulse input
.
Option: Function:
[0] * No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[5] DC-brake inverse
[6] Stop inverse
[7] External interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[34] Ramp bit 0
[36] Mains failure inverse
[37] Fire Mode
[52] Run permissive
[53] Hand start
[54] Auto start
[55] DigiPot increase
[56] DigiPot decrease
[57] DigiPot clear
How to program the Frequency Converter
6-8 BAS-SVX19C-EN
