36-** Programmable I/O Option
Par.
No. #
Parameter description Default value 4-set-up Change
during op-
eration
Conver-
sion in-
dex
Type
36-0* I/O Mode
36-00 Terminal X49/1 Mode [1] Voltage All set-ups TRUE - Uint8
36-01 Terminal X49/3 Mode [1] Voltage All set-ups TRUE - Uint8
36-02 Terminal X49/5 Mode [1] Voltage All set-ups TRUE - Uint8
36-03 Terminal X49/7 Mode
[0] Voltage
0-10V
All set-ups TRUE - Uint8
36-04 Terminal X49/9 Mode
[0] Voltage
0-10V All set-ups TRUE - Uint8
36-05 Terminal X49/11 Mode
[0] Voltage
0-10V
All set-ups TRUE - Uint8
36-1* Analog Input X49/1
36-10 Terminal X49/1 Low Voltage 0.07 V All set-ups TRUE -2 Int16
36-11 Terminal X49/1 Low Current 4.00 mA All set-ups TRUE -5 Int16
36-12 Terminal X49/1 High Voltage 10.00 V All set-ups TRUE -2 Int16
36-13 Terminal X49/1 High Current 20.00 mA All set-ups TRUE -5 Int16
36-14
Term. X49/1 Low Ref./Feedb.
Value
0.000 N/A All set-ups TRUE -3 Int32
36-15
Term. X49/1 High Ref./Feedb.
Value 100.000 N/A All set-ups TRUE -3 Int32
36-16
Term. X49/1 Filter Time Con-
stant
0.001 s All set-ups TRUE -3 Uint16
36-17 Term. X49/1 Live Zero [1] Enabled All set-ups TRUE - Uint8
36-2* Analog Input X49/3
36-20 Terminal X49/3 Low Voltage 0.07 V All set-ups TRUE -2 Int16
36-21 Terminal X49/3 Low Current 4.00 mA All set-ups TRUE -5 Int16
36-22 Terminal X49/3 High Voltage 10.00 V All set-ups TRUE -2 Int16
36-23 Terminal X49/3 High Current 20.00 mA All set-ups TRUE -5 Int16
36-24
Term. X49/3 Low Ref./Feedb.
Value 0.000 N/A All set-ups TRUE -3 Int32
36-25
Term. X49/3 High Ref./Feedb.
Value
100.000 N/A All set-ups TRUE -3 Int32
36-26
Term. X49/3 Filter Time Con-
stant 0.001 s All set-ups TRUE -3 Uint16
36-27 Term. X49/3 Live Zero [1] Enabled All set-ups TRUE - Uint8
36-3* Analog Input X49/5
36-30 Terminal X49/5 Low Voltage 0.07 V All set-ups TRUE -2 Int16
36-31 Terminal X49/5 Low Current 4.00 mA All set-ups TRUE -5 Int16
36-32 Terminal X49/5 High Voltage 10.00 V All set-ups TRUE -2 Int16
36-33 Terminal X49/5 High Current 20.00 mA All set-ups TRUE -5 Int16
36-34
Term. X49/5 Low Ref./Feedb.
Value
0.000 N/A All set-ups TRUE -3 Int32
36-35
Term. X49/5 High Ref./Feedb.
Value 100.000 N/A All set-ups TRUE -3 Int32
36-36
Term. X49/5 Filter Time Con-
stant
0.001 s All set-ups TRUE -3 Uint16
36-37 Term. X49/5 Live Zero [1] Enabled All set-ups TRUE - Uint8
36-4* Output X49/7
36-40 Terminal X49/7 analog Output
[0] No opera-
tion All set-ups TRUE - Uint8
36-41 Terminal X49/7 Digital Output
[0] No opera-
tion
All set-ups TRUE - Uint8
36-42 Terminal X49/7 Min. Scale 0.00 % All set-ups TRUE -2 Int16
36-43 Terminal X49/7 Max. Scale 100.00 % All set-ups TRUE -2 Int16
36-44 Terminal X49/7 Bus Control 0.00 % All set-ups TRUE -2 N2
36-45 Terminal X49/7 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
How to program the Frequency Converter
BAS-SVX19C-EN 6-93
