Q3-4 Application Settings
Q3-40 Fan Functions Q3-41 Pump Functions Q3-42 Compressor Functions
Par. 22-60
Broken Belt Function Par. 22-22 Low Speed Detection Par. 1-03 Torque Characteristics
Par. 22-61
Broken Belt Torque Par. 22-23 No-Flow Function Par. 1-71 Start Delay
Par. 22-62
Broken Belt Delay Par. 22-24 No-Flow Delay Par. 22-75 Short Cycle Protection
Par. 4-64
Semi-Auto Bypass Set-
up
Par. 22-40
Minimum Run Time Par. 22-76 Interval between Starts
Par. 1-03
Torque Characteristics Par. 22-41 Minimum Sleep Time Par. 22-77 Minimum Run Time
Par. 22-22
Low Speed Detection Par. 22-42 Wake-up Speed [RPM] Par. 5-01 Terminal 27 Mode
Par. 22-23
No-Flow Function Par. 22-43 Wake-up Speed [Hz] Par. 5-02 Terminal 29 Mode
Par. 22-24
No-Flow Delay Par. 22-44 Wake-up Ref./FB Differ-
ence
Par. 5-12
Terminal 27 Digital Input
Par. 22-40
Minimum Run Time Par. 22-45 Setpoint Boost Par. 5-13 Terminal 29 Digital Input
Par. 22-41
Minimum Sleep Time Par. 22-46 Maximum Boost Time Par. 5-40 Function Relay
Par. 22-42
Wake-up Speed [RPM] par. 1-73 Flying Start
Par. 22-43
Wake-up Speed [Hz] Par. 1-86 Trip Speed Low [RPM]
Par. 22-44
Wake-up Ref./FB Dif-
ference
Par. 1-03
Torque Characteristics Par. 1-87 Trip Speed Low [Hz]
Par. 22-45
Setpoint Boost Par. 1-73 Flying Start
Par. 22-46
Maximum Boost Time
Par. 2-10
Brake Function
Par. 2-16
AC brake Max. Current
Par. 2-17
Over-voltage Control
Par. 1-73
Flying Start
Par. 1-71
Start Delay
Par. 1-80
Function at Stop
Par. 2-00
DC Hold/Preheat Cur-
rent
Par. 4-10
Motor Speed Direction
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, left position.
[0] * None No display value selected
[37] Display Text 1 Enables an individual text string to be written, for display in the keypad
or to be read via serial communication.
[38] Display Text 2 Enables an individual text string to be written, for display in the keypad
or to be read via serial communication.
[39] Display Text 3 Enables an individual text string to be written, for display in the keypad
or to be read via serial communication.
[89] Date and Time Readout Displays the current date and time.
[953] Profibus Warning Word Displays Profibus communication warnings.
[1005] Readout Transmit Error
Counter
View the number of CAN control transmission errors since the last pow-
er-up.
[1006] Readout Receive Error
Counter
View the number of CAN control receipt errors since the last power-up.
[1007] Readout Bus Off Counter View the number of Bus Off events since the last power-up.
