6-** Analog In / Out
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8
6-01 Live Zero Timeout Function [0] Off All set-ups TRUE - Uint8
6-02
Fire Mode Live Zero Time-
out Function [0] Off All set-ups TRUE - Uint8
6-1* Analog Input 53
6-10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Int16
6-11 Terminal 53 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-12 Terminal 53 Low Current 4.00 mA All set-ups TRUE -5 Int16
6-13 Terminal 53 High Current 20.00 mA All set-ups TRUE -5 Int16
6-14
Terminal 53 Low Ref./Feedb.
Value
22 Hz IntelliPak
35 Hz Voyager
III All set-ups TRUE -3 Int32
6-15
Terminal 53 High Ref./
Feedb. Value
ExpressionLi-
mit
All set-ups TRUE -3 Int32
6-16
Terminal 53 Filter Time Con-
stant 0.001 s All set-ups TRUE -3 Uint16
6-17 Terminal 53 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-2* Analog Input 54
6-20 Terminal 54 Low Voltage 0.07 V All set-ups TRUE -2 Int16
6-21 Terminal 54 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-22 Terminal 54 Low Current 4.00 mA All set-ups TRUE -5 Int16
6-23 Terminal 54 High Current 20.00 mA All set-ups TRUE -5 Int16
6-24
Terminal 54 Low Ref./Feedb.
Value
0.000 N/A All set-ups TRUE -3 Int32
6-25
Terminal 54 High Ref./
Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
6-26
Terminal 54 Filter Time Con-
stant
0.001 s All set-ups TRUE -3 Uint16
6-27 Terminal 54 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-3* Analog Input X30/11
6-30
Terminal X30/11 Low Volt-
age 0.07 V All set-ups TRUE -2 Int16
6-31
Terminal X30/11 High Volt-
age
10.00 V All set-ups TRUE -2 Int16
6-34
Term. X30/11 Low Ref./
Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-35
Term. X30/11 High Ref./
Feedb. Value
100.000 N/A All set-ups TRUE -3 Int32
6-36
Term. X30/11 Filter Time
Constant 0.001 s All set-ups TRUE -3 Uint16
6-37 Term. X30/11 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-4* Analog Input X30/12
6-40
Terminal X30/12 Low Volt-
age
0.07 V All set-ups TRUE -2 Int16
6-41
Terminal X30/12 High Volt-
age 10.00 V All set-ups TRUE -2 Int16
6-44
Term. X30/12 Low Ref./
Feedb. Value
0.000 N/A All set-ups TRUE -3 Int32
6-45
Term. X30/12 High Ref./
Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
6-46
Term. X30/12 Filter Time
Constant
0.001 s All set-ups TRUE -3 Uint16
6-47 Term. X30/12 Live Zero [1] Enabled All set-ups TRUE - Uint8
