Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
6-5* Analog Output 42
6-50 Terminal 42 Output null All set-ups TRUE - Uint8
6-51
Terminal 42 Output Min
Scale
0.00 % All set-ups TRUE -2 Int16
6-52
Terminal 42 Output Max
Scale 100.00 % All set-ups TRUE -2 Int16
6-53
Terminal 42 Output Bus
Control
0.00 % All set-ups TRUE -2 N2
6-54
Terminal 42 Output Timeout
Preset 0.00 % 1 set-up TRUE -2 Uint16
6-6* Analog Output X30/8
6-60 Terminal X30/8 Output
[0] No opera-
tion All set-ups TRUE - Uint8
6-61 Terminal X30/8 Min. Scale 0.00 % All set-ups TRUE -2 Int16
6-62 Terminal X30/8 Max. Scale 100.00 % All set-ups TRUE -2 Int16
6-63
Terminal X30/8 Output Bus
Control
0.00 % All set-ups TRUE -2 N2
6-64
Terminal X30/8 Output
Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
How to program the Frequency Converter
BAS-SVX19C-EN 6-75
