Trane TR200 - 20-** Drive Closed Loop

20-** Drive Closed Loop
Par.
No. #
Parameter description Default value 4-set-up Change
during op-
eration
Conver-
sion index
Type
20-0* Feedback
20-00 Feedback 1 Source
[2] Analog in-
put 54 All set-ups TRUE - Uint8
20-01 Feedback 1 Conversion [0] Linear All set-ups FALSE - Uint8
20-02 Feedback 1 Source Unit null All set-ups TRUE - Uint8
20-03 Feedback 2 Source [0] No function All set-ups TRUE - Uint8
20-04 Feedback 2 Conversion [0] Linear All set-ups FALSE - Uint8
20-05 Feedback 2 Source Unit null All set-ups TRUE - Uint8
20-06 Feedback 3 Source [0] No function All set-ups TRUE - Uint8
20-07 Feedback 3 Conversion [0] Linear All set-ups FALSE - Uint8
20-08 Feedback 3 Source Unit null All set-ups TRUE - Uint8
20-12 Reference/Feedback Unit null All set-ups TRUE - Uint8
20-13
Minimum Reference/
Feedb.
0.000 Proc-
essCtrlUnit All set-ups TRUE -3 Int32
20-14
Maximum Reference/
Feedb.
100.000 Proc-
essCtrlUnit
All set-ups TRUE -3 Int32
20-2* Feedback/Setpoint
20-20 Feedback Function [3] Minimum All set-ups TRUE - Uint8
20-21 Setpoint 1
0.000 Proc-
essCtrlUnit All set-ups TRUE -3 Int32
20-22 Setpoint 2
0.000 Proc-
essCtrlUnit
All set-ups TRUE -3 Int32
20-23 Setpoint 3
0.000 Proc-
essCtrlUnit All set-ups TRUE -3 Int32
20-3* Feedback Adv. Conv.
20-30 Refrigerant [0] R22 All set-ups TRUE - Uint8
20-31
User Defined Refrigerant
A1
10.0000 N/A All set-ups TRUE -4 Uint32
20-32
User Defined Refrigerant
A2 -2250.00 N/A All set-ups TRUE -2 Int32
20-33
User Defined Refrigerant
A3
250.000 N/A All set-ups TRUE -3 Uint32
20-7* PID Autotuning
20-70 Closed Loop Type [0] Auto 2 set-ups TRUE - Uint8
20-71 PID Performance [0] Normal 2 set-ups TRUE - Uint8
20-72 PID Output Change 0.10 N/A 2 set-ups TRUE -2 Uint16
20-73 Minimum Feedback Level
-999999.000
ProcessCtrlU-
nit 2 set-ups TRUE -3 Int32
20-74 Maximum Feedback Level
999999.000
ProcessCtrlU-
nit
2 set-ups TRUE -3 Int32
20-79 PID Autotuning [0] Disabled All set-ups TRUE - Uint8
20-8* PID Basic Settings
20-81
PID Normal/ Inverse Con-
trol [0] Normal All set-ups TRUE - Uint8
20-82 PID Start Speed [RPM]
ExpressionLi-
mit
All set-ups TRUE 67 Uint16
20-83 PID Start Speed [Hz]
ExpressionLi-
mit All set-ups TRUE -1 Uint16
20-84 On Reference Bandwidth 5 % All set-ups TRUE 0 Uint8
How to program the Frequency Converter
6-86 BAS-SVX19C-EN
