Trane TR200 - Motor Speed Low Limit (RPM; Hz); Motor Speed High Limit (RPM); Motor Speed High Limit (Hz); Jog Speed (RPM)

4-11 Motor Speed Low Limit [RPM]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the minimum limit for motor speed. The Motor Speed Low Limit
can be set to correspond to the manufacturer’s recommended minimum
motor speed. The Motor Speed Low Limit must not exceed the setting in
par. 4-13
Motor Speed High Limit [RPM].
4-12 Motor Speed Low Limit [Hz]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the minimum limit for motor speed. The Motor Speed Low Limit
can be set to correspond to the minimum output frequency of the motor
shaft. The Speed Low Limit must not exceed the setting in
par. 4-14
Motor Speed High Limit [Hz].
4-13 Motor Speed High Limit [RPM]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the maximum limit for motor speed. The Motor Speed High Limit
can be set to correspond to the manufacturer’s maximum rated motor.
The Motor Speed High Limit must exceed the setting in par. 4-11
Motor
Speed Low Limit [RPM]. Only par. 4-11 Motor Speed Low Limit [RPM] or
par. 4-12
Motor Speed Low Limit [Hz] will be displayed depending on
other parameters in the Main Menu and depending on default settings
dependant on global location.
Max. output frequency cannot exceed 10% of the inverter switching frequency (par. 14-01
Switching Frequency).
Any changes in par. 4-13
Motor Speed High Limit [RPM] will reset the value in par. 4-53 Warning Speed High to the
same value as set in par. 4-13
Motor Speed High Limit [RPM].
4-14 Motor Speed High Limit [Hz]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the maximum limit for motor speed. The Motor Speed High Limit
can be set to correspond to the manufacturer’s recommended maximum
of the motor shaft. The Motor Speed High Limit must exceed the in
par. 4-12
Motor Speed Low Limit [Hz]. Only par. 4-11 Motor Speed Low
Limit [RPM] or par. 4-12 Motor Speed Low Limit [Hz] will be displayed
depending on other parameters in the Main Menu and depending on
default settings dependant on global location.
NOTE
Max. output frequency cannot exceed 10% of the inverter switching frequency (par. 14-01 Switching Frequency).
3-19 Jog Speed [RPM]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter a value for the jog speed n
JOG
, which is a fixed output speed. The
frequency converter runs at this speed when the jog function is activated.
The maximum limit is defined in par. .
See also par. 3-80
Jog Ramp Time.
How to program the Frequency Converter
BAS-SVX19C-EN 6-7
