Trane TR200 - 3-15 Reference 1 Source; 3-16 Reference 2 Source

3-15 Reference 1 Source
Option: Function:
Select the reference input to be used for the first reference signal.
Par. 3-15
Reference 1 Source, par. 3-16 Reference 2 Source and
par. 3-17
Reference 3 Source define up to three different reference sig-
nals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] No function
[1] * Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[26] Analog Input X49/1
[27] Analog Input X49/3
[28] Analog Input X49/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-16 Reference 2 Source
Option: Function:
Select the reference input to be used for the second reference signal.
par. 3-15
Reference 1 Source, par. 3-16 Reference 2 Source and
par. 3-17
Reference 3 Source define up to three different reference sig-
nals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] * Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[26] Analog Input X49/1
How to program the Frequency Converter
BAS-SVX19C-EN 6-29
