Trane TR200 - 1-** Load;Motor; Load; Motor

1-** Load / Motor
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
1-0* General Settings
1-00 Configuration Mode null All set-ups TRUE - Uint8
1-03 Torque Characteristics
[1] Variable
Torque
All set-ups TRUE - Uint8
1-2* Motor Data
1-20 Motor Power [kW]
ExpressionLi-
mit
All set-ups FALSE 1 Uint32
1-21 Motor Power [HP]
Reference Mo-
tor Nameplate
HP All set-ups FALSE -2 Uint32
1-22 Motor Voltage
Reference Mo-
tor Nameplate
Voltage
All set-ups FALSE 0 Uint16
1-23 Motor Frequency
ExpressionLi-
mit All set-ups FALSE 0 Uint16
1-24 Motor Current
Reference Mo-
tor Nameplate
FLA
All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed
Reference Mo-
tor Nameplate
Rated Speed All set-ups FALSE 67 Uint16
1-28 Motor Rotation Check [0] Off All set-ups FALSE - Uint8
1-29
Automatic Motor Adaptation
(AMA) [0] Off All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs)
ExpressionLi-
mit All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr)
ExpressionLi-
mit
All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh)
ExpressionLi-
mit All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe)
ExpressionLi-
mit
All set-ups FALSE -3 Uint32
1-39 Motor Poles
ExpressionLi-
mit All set-ups FALSE 0 Uint8
1-5* Load Indep. Setting
1-50
Motor Magnetisation at Zero
Speed 100 % All set-ups TRUE 0 Uint16
1-51
Min Speed Normal Magnetis-
ing [RPM]
ExpressionLi-
mit
All set-ups TRUE 67 Uint16
1-52
Min Speed Normal Magnetis-
ing [Hz]
ExpressionLi-
mit All set-ups TRUE -1 Uint16
1-58 Flystart Test Pulses Current 30 % All set-ups FALSE 0 Uint16
1-59
Flystart Test Pulses Frequen-
cy 200 % All set-ups FALSE 0 Uint16
1-6* Load Depen. Setting
1-60
Low Speed Load Compensa-
tion 100 % All set-ups TRUE 0 Int16
1-61
High Speed Load Compensa-
tion
100 % All set-ups TRUE 0 Int16
1-62 Slip Compensation 0 % All set-ups TRUE 0 Int16
1-63
Slip Compensation Time Con-
stant
ExpressionLi-
mit
All set-ups TRUE -2 Uint16
1-64 Resonance Dampening 100 % All set-ups TRUE 0 Uint16
1-65
Resonance Dampening Time
Constant
5 ms All set-ups TRUE -3 Uint8
How to program the Frequency Converter
6-66 BAS-SVX19C-EN
