Electrical Installation
Fuse Selection for Drives with Internal Drive Fusing
For drives ordered with internal drive fusing
The illustrations below show where input mains power, output motor power, and relays are located for drives
with internal fusing. Replacement fuse ratings for internal fuses are also provided.
1. Relay terminals
2. Motor power terminals
3. Input power terminals
130BX300.10
1
2
3
Figure 4. 1: A2, A3
1. Drive fuses
2. Relay terminals
3. Motor power terminals
4. Input power terminals
Figure 4. 2: A5
BAS-SVX19C-EN 4-1
