6-27 Terminal 54 Live Zero
Option: Function:
This parameter makes it possible to disable the Live Zero monitoring.
E.g. to be used if the analog outputs are used as part of a de-central I/O
system (e.g. when not as part of any frequency converter related control
functions, but feeding a Building Management System with data).
[0] Disabled
[1] * Enabled
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output. A motor
current of 20 mA corresponds to I
max
.
[0] * No operation
[100] Output freq. 0-100 0 - 100 Hz, (0-20 mA)
[101] Reference Min-Max Minimum reference - Maximum reference, (0-20 mA)
[102] Feedback +-200% -200% to +200% of par. 20-14
Maximum Reference/Feedb., (0-20 mA)
[103] Motor cur. 0-Imax 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current), (0-20 mA)
[104] Torque 0-Tlim 0 - Torque limit (par. 4-16
Torque Limit Motor Mode), (0-20 mA)
[105] Torque 0-Tnom 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom 0 - Motor rated power, (0-20 mA)
[107] * Speed 0-HighLim 0 - Speed High Limit (par. 4-13
Motor Speed High Limit [RPM] and
par. 4-14
Motor Speed High Limit [Hz]), (0-20 mA)
[113] Ext. Closed Loop 1 0 - 100%, (0-20 mA)
[114] Ext. Closed Loop 2 0 - 100%, (0-20 mA)
[115] Ext. Closed Loop 3 0 - 100%, (0-20 mA)
[130] Out frq 0-100 4-20mA 0 - 100 Hz
[131] Reference 4-20mA Minimum Reference - Maximum Reference
[132] Feedback 4-20mA -200% to +200% of par. 20-14
Maximum Reference/Feedb.
[133] Motor cur. 4-20mA 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current)
[134] Torq.0-lim 4-20 mA 0 - Torque limit (par. 4-16
Torque Limit Motor Mode)
[135] Torq.0-nom 4-20mA 0 - Motor rated torque
[136] Power 4-20mA 0 - Motor rated power
[137] Speed 4-20mA 0 - Speed High Limit (4-13 and 4-14)
[139] Bus ctrl. 0 - 100%, (0-20 mA)
[140] Bus ctrl. 4-20 mA 0 - 100%
[141] Bus ctrl t.o. 0 - 100%, (0-20 mA)
