Trane TR200 - 14-** Special Functions

14-** Special Functions
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
14-0* Inverter Switching
14-00 Switching Pattern [0] 60 AVM All set-ups TRUE - Uint8
14-01 Switching Frequency
8 kHz (Except
above 30hp
208/230V and
above 60hp
460/575V are
set to 5 kHz)
All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-04 PWM Random [0] Off All set-ups TRUE - Uint8
14-1* Mains On/Off
14-10 Mains Failure [0] No function All set-ups FALSE - Uint8
14-11
Mains Voltage at Mains
Fault
ExpressionLi-
mit All set-ups TRUE 0 Uint16
14-12
Function at Mains Imbal-
ance
[3] Derate All set-ups TRUE - Uint8
14-2* Reset Functions
14-20 Reset Mode
[3] Automatic
reset x 3
All set-ups TRUE - Uint8
14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16
14-22 Operation Mode
[0] Normal op-
eration
All set-ups TRUE - Uint8
14-23 Typecode Setting null 2 set-ups FALSE - Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip Delay at Inverter Fault
ExpressionLi-
mit All set-ups TRUE 0 Uint8
14-28 Production Settings [0] No action All set-ups TRUE - Uint8
14-29 Service Code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl.
14-30
Current Lim Ctrl, Propor-
tional Gain 100 % All set-ups FALSE 0 Uint16
14-31
Current Lim Ctrl, Integra-
tion Time
0.020 s All set-ups FALSE -3 Uint16
14-32 Current Lim Ctrl, Filter Time 26.0 ms All set-ups TRUE -4 Uint16
14-4* Energy Optimizing
14-40 VT Level 66 % All set-ups FALSE 0 Uint8
14-41
AEO Minimum Magnetisa-
tion
ExpressionLi-
mit
All set-ups TRUE 0 Uint8
14-42 Minimum AEO Frequency 10 Hz All set-ups TRUE 0 Uint8
14-43 Motor Cosphi
ExpressionLi-
mit
All set-ups TRUE -2 Uint16
14-5* Environment
14-50 RFI Filter [1] On 1 set-up FALSE - Uint8
14-52 Fan Control [0] Auto All set-ups TRUE - Uint8
14-53 Fan Monitor [1] Warning All set-ups TRUE - Uint8
14-59
Actual Number of Inverter
Units
ExpressionLi-
mit 1 set-up FALSE 0 Uint8
14-6* Auto Derate
14-60
Function at Over Tempera-
ture [1] Derate All set-ups TRUE - Uint8
14-61
Function at Inverter Over-
load
[1] Derate All set-ups TRUE - Uint8
14-62
Inv. Overload Derate Cur-
rent 95 % All set-ups TRUE 0 Uint16
