Trane TR200 - Type Code String Low and Medium Power

Type Code String low and medium power
TR
2
0
Description Pos Possible choice
Product group & FC Series 1-6 TR-200
Power rating 8-10 1.1- 1200 kW (P1K1 - P1M2)
Number of phases 11 Three phases (T)
Mains voltage 11-12
T 2: 200-240 VAC
T 4: 380-480 VAC
Enclosure 13-15
E20: IP20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
E66: IP66
P21: IP21/NEMA Type 1 w/backplate
P55: IP55/NEMA Type 12 w/backplate
RFI filter 16-17
H1: RFI filter class A1/B
H2: RFI filter class A2
H3: RFI filter class A1/B (reduced cable length)
Hx: No RFI filter
Brake 18 X: No brake chopper included
Display 19
G: Graphical Local Control Panel (keypad)
X: No Local Control Panel
Coating PCB 20
X. No coated PCB
C: Coated PCB
Mains option 21
X: No Mains disconnect switch and Load Sharing
1: With Mains disconnect switch (IP55 only)
8: Mains disconnect and Load Sharing
D: Load Sharing
See Chapter 8 for max. cable sizes.
Adaptation 22
X: Standard
0: European metric thread in cable entries.
Adaptation 23 Reserved
Software release 24-27 Actual software
Software language 28
A options 29-30
AX: No options
A4: MCA 104 DeviceNet
AF: MCA 115 LonWorks
AE: MCA 116 BACnet gateway
B options 31-32
BX: No option
BK: MCB 101 General purpose I/O option
BP: MCB 105 Relay option
C0 options MCO 33-34 CX: No options
C1 options 35 X: No options
C option software 36-37 XX: Standard software
D options 38-39
DX: No option
D0: DC back-up
Table 2. 2: Type code description.
