[27] Analog Input X49/3
[28] Analog Input X49/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
4-10 Motor Speed Direction
Option: Function:
Selects the motor speed direction required.
Use this parameter to prevent unwanted reversing.
[0] Clockwise Only operation in clockwise direction will be allowed.
[2] * Both directions Operation in both clockwise and anti-clockwise direction will be allowed.
The setting in par. 4-10
Motor Speed Direction has impact on the Flying Start in par. 1-73 Flying Start.
4-53 Warning Speed High
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the n
HIGH
value. When the motor speed exceeds this limit (n
HIGH
),
the display reads SPEED HIGH. The signal outputs can be programd to
produce a status signal on terminal 27 or 29 and on relay output 01 or
02. program the upper signal limit of the motor speed, n
HIGH
, within the
normal working range of the frequency converter. Refer to the drawing
in this section.
Any changes in par. 4-13
Motor Speed High Limit [RPM] will reset the value in par. 4-53 Warning Speed High to the
same value as set in par. 4-13
Motor Speed High Limit [RPM].
If a different value is needed in par. 4-53
Warning Speed High, it must be set after programming of par. 4-13 Motor
Speed High Limit [RPM]
4-56 Warning Feedback Low
Range: Function:
-999999.
999
Proc-
essCtrlU-
nit*
[Application dependant] Enter the lower feedback limit. When the feedback falls below this limit,
the display reads Feedb Low. The signal outputs can be programd to
produce a status signal on terminal 27 or 29 and on relay output 01 or
02.
4-57 Warning Feedback High
Range: Function:
999999.
999
Proc-
essCtrlU-
nit*
[Application dependant] Enter the upper feedback limit. When the feedback exceeds this limit, the
display reads Feedb High. The signal outputs can be programd to pro-
duce a status signal on terminal 27 or 29 and on relay output 01 or 02.
4-64 Semi-Auto Bypass Set-up
Option: Function:
[0] * Off No function
How to program the Frequency Converter
6-30 BAS-SVX19C-EN
